6.0 / 7.5 / 9.0 / 10.5 / 12.0 Metre Tapered External Halyard Flagpoles
| PRODUCT CODE | A Flagpole Height (metres) | B Taper Length (millimetres) | C/D OD Diameter (millimetres) | Wall Thickness (millimetres) | Wind region category |
|---|---|---|---|---|---|
| MS – 4 | 6.0 | 1800 | 80/48 | 2.0 | Region A cat 2 |
| MS – 7 | 6.0 | 3000 | 100/57 | 2.3 | Region A cat 2 |
| MS – 12 | 7.5 | 1800 | 80/48 | 2.0 | Region A cat 3 |
| MS – 15 | 9.0 | 3000 | 100/57 | 2.3 | Region A cat 3 |
| MS – 17 | 10.5 | 3500 | 125/75 | 3.0 | Region A cat 2.5 |
| MS – 19 | 12.0 | 3500 | 125/75 | 3.0 | Region A cat 3 |
Nb. View Cyclone Rated Flagpoles and Yard Arm Flagpoles
Specifications
- Manufactured from 6063 T6 high-tensile marine grade aluminium tube (AS1664.1)
- Spun-tapered for the top section of pole
- UV-stabilised heavy-duty gloss white powder coat finish to AS3715-2002
(Dulux Pearl White as standard, other colours available also clear anodised finish available)
- UV-stabilized nylon mushroom finial and flag clips
- UV-stabilized 5mm polyester external halyard rope
- UV-stabilized nylon horn cleat is set at 1135mm from base of flagpole – wheelchair accessible height
- HD galvanized steel spigot with flange base plate and machined nylon bushes prevents dis-similar metal contact AS4100 and AS 1554.1
- HD galvanized steel bolt cage with twin nuts and washers
- Engineering certification in accordance with AS1170.2 and AS1170.4 Wind Load Standards
6.0 / 7.5 Un-tapered External Halyard Flagpoles
| PRODUCT CODE | A Flagpole Height (metres) | B Taper Length (millimetres) | C/D OD Diameter (millimetres) | Wall Thickness (millimetres) | Wind region category |
|---|---|---|---|---|---|
| MS – 5 | 6.0 | un-tapered | 80/80 | 2.3 | Region A cat 2 |
| MS – 13 | 7.5 | un-tapered | 80/80 | 2.3 | Region A cat 2 |
*Nb. Specifications as above apart from being un-tapered tube and manufactured from 6106T6 aluminium
